JOS-1AW

Components

Mobile-Ready Box Set with Surface-Mount Door Station

This box kit contains the JO-1MDW an analog answering station with a 7” touchscreen display and WiFi capabilities, allowing mobile apps to be added to a JO system. The JO-1MDW has two normally open dry contacts and built-in memory that can be utilized to record calls, with the option of increasing the storage capacity using a MicroSD card. The box kit also contains the JO-DA a surface mount analog door station with an IP54 rating and an adjustable switch allowing the camera angle to be manually set during installation. The box kit also contains the PS-1820UL a UL and CSA listed 18v Class II power supply.

System Highlights

Mobile App

Large Monitor

Jump to:

FEATURES
SPECS
COMPONENTS
LITERATURE
RELATED INFORMATION

Features

Connect up to 8 mobile devices per system
Store calls using onboard memory
Add a MicroSD card to increase memory to a maximum of 32 GB
JO-DA activates white LED light for visibility at night
Activate door release on site or off using the mobile app

Specs

Inside Monitor

Model: JO-1MDW
Video Display: 7" TFT Touchscreen
Mounting: Surface wall mount or desk mount with MCW-S stand
Internal Call Recording: 10 calls max. @ 10 seconds/call
Memory Expansion: micro SDHC card slot, 32GB max.
Call Recording with max memory: 1,000 calls max. @ 10 seconds/call
Communication style: Handsfree or PTT
Wireless Frequency: 2.4 GHz
Wireless Protocol: 802.11b, 802.11g, and 802.11n (Wireless B/G/N)

App

Model: Intercom App Type B
Max per system: 8 devices
Available at: Apple App Store℠ or Google Play™

Video Door Station

Model: JO-DA
Power Source: Supplied by inside monitor
Camera: 1/4 inch color CMOS
Mounting: Surface wall mount using a 1 gang electrical box
Faceplate Material: Self-extinguishing PC + ABS plastic
Enclosure Rating: IP54
Communication style: Handsfree
Operational Tempature: -40°~140° F (-40° ~ 60° C)
Volume: 69.7 dB
Wiring to master: 2-cond., low cap, non-shielded
Max. Wire distance: 165' (22AWG) 330' (18AWG)
