System Highlights
Access Control

AC Nio™

Components

AC Nio™ is the software at the heart of the AC Series access control system. AC Nio is intuitive, powerful, and scalable to match the needs of any application. Manage one site or several from the same interface and let site managers control their own systems without accessing other areas or tenants. User information can also be imported from external sources, saving time and hassle.

It provides security and flexibility for managers and users alike. Administrators can configure Access Privilege Groups to easily manage large number of users with the same access needs, or to configure more granular permissions for individuals. Advanced scheduling options, including temporary and holiday schedules, make it simple to grant and restrict access as needed. Users and managers can utilize the AC Key mobile app, allowing them to send visitors temporary credentials by text or email, providing flexible and secure access on the fly. AC Nio™ also lets managers track site access with real time activity reports, including user and muster reports, and empower designated users to initiate emergency lockdowns.

AC Nio can either run on a PC or server, including the option to use an AC-HOST, an embedded Linux system with AC Nio pre-installed. There are multiple licensing options available depending on the size of the system. See the Features section below for more details on licensing terms and supported functions.

System Highlights
Access Control
Features
  • Scalable to cover small and medium sites
  • User friendly programming and management interface
  • AC Nio Admin™ allows admins to make changes from their mobile device
  • Custom scheduling for all users and doors, including Holiday Schedules
  • Issue temporary guest passes with AC Key™
  • LDAP integration (Active Directory)
  • Generate granular reports on user and door activity
  • VMS Integration
  • Create custom actions with the scripting engine
  • Create up to five system partitions
  • Manage doors without a card reader
  • IP camera integration
  • Manage elevators

Some features require particular licenses to be selected.



(1 or 5 year license available) AC-NIO-ESS AC-NIO-SBS
Doors 40 80
Cameras 40 80
Partitions 1 5
LDAP NO YES
Unmanaged Doors NO YES
Elevator Control NO YES
AC-HOST YES NO



If you need a larger system capacity with more doors and cameras, contact your local rep, we’re here to assist.




Specs

Operating System:

Windows® 7 Professional, Windows® 7 Enterprise, Windows® 7 Ultimate or later

CPU:

32 bit (x86) processor or 64 bit (x64) processor, 2 GHz or faster

Memory:

4 GB or higher

Required Storage:

1 GB (additional space required for database)

Runtime:

.NET Framework 4.5 or later

SQL Server:

Microsoft SQL Server 2008 or SQL Server 2008 Express or higher
